Features:
High-speed USB offline control system. On this series of machine, framework integrally designed, working stable, economical and practical type machine is widely used.
Applications:
1. Suitable for small area craft processing.Engraving varies graphics and letter on double color board, wood, bamboo, organic glass, clothing, leather etc.
2. Suitable for engraving on non-metal materials, all kinds of stamp, like horn, wooden,red plastic, organic glass etc.
3. Carve name, model, label, design and date on electronic parts.
4. Cut acrylic and organic glass.
Technical Parameters:
|
Laser Model
|
RJ4040
|
|
Working Area
|
400 x400mm
|
|
Laser Type
|
Glass Sealed-off CO2 laser tube,wavelength 10.6µm
|
|
Laser Power
|
40W
|
|
Laser Tube Cooling
|
Purified Recycling Water Cooling
|
|
Laser Output Control
|
0—100% Non Section Control, Software inner adjustment from 0—100%
|
|
Control System and Driver
|
DSP Control, High Subdivision Driver, Stepper Motor
|
|
Engraving Speed
|
0-400mm/s
|
|
Cutting Speed
|
0-200mm/s
|
|
Working Voltage
|
AC220V/110V±10% 50/60HZ
|
|
Position Accuracy
|
<±0.01mm
|
|
Minimum Letter Size
|
English:1mm
|
|
Machine Power
|
≤300W
|
|
Working Environment
|
Temperature:0-45;Humidity:5%-95%
|
|
Supported Format
|
BMP,PLT
|
