Applications:
Wood, paper, leather, fabric, organic glass, epoxy resin, acrylic, woolen, plastic,
Rubber, Ceramic tile, crystal, Stone, bamboo products and other non-metal materials.
Applicable industry:
The machine is suitable for Garment, leather, stuffed toy, computerized embroidery and clipping industry.
Parameters:
|
Model
|
RJ1325
|
|
Working Area
|
1300×2500mm
|
|
Laser Type
|
CO2 Sealed Laser Tube, Wavelength 10.6μm
|
|
Laser Tube Power
|
60W, 80W, 100W, 150W
|
|
Cooling System
|
Water Cooling
|
|
Power Adjustment
|
0-100% Stepless Control, 0-100% Adjustable in Software
|
|
Control and Driving
|
High Speed DSP Control, Stepper Motor High Subdivide Driving
|
|
Engraving Speed
|
0-9000mm/min
|
|
Cutting Speed
|
0-5000mm/min
|
|
Working Voltage
|
AC220V/110V±10% 50HZ/60HZ
|
|
Reposition Accuracy
|
≤±0.01mm
|
|
Minimum Letter Size
|
Chinese: 1.5mm English: 1mm
|
|
Consuming Power
|
≤1500W
|
|
Running Environment
|
Temperature: 0-45℃; Humidity: 5%-95% (free of condensed water)
|
|
Supported Format
|
PLT, DST, DXF, BMP, AI, Support AutoCAD, CorelDraw Output Directly
|
